日本進口油研單向節流閥
上海乾拓貿易有限公司
聯系人:楊江玲
企業QQ:2880626083
手 機:18917074297(微信)
電 話:021-39529830-8012
郵箱;18917074297@163.com
地址:上海市嘉定區江橋嘉涌路6號樓713室
This valve is used to regulate an actuator speed in a circuit
where line pressure is almost steady and small fluctuation of o il flow due to
pressure changes is permitted. Integrated check valve allows reversed free flow from outlet to inlet port.
Valve Model Numbers
SRG/SRCG-03 SRG/SRCG-06 SRG/SRCG-10
Socket Head Cap Screw Japanese Std. "JIS" and European Design Std. N. American Design Std.
M10 × 45 Lg. M10 × 50 Lg. M10 × 55 Lg.
Due caution must be paid to maintaining control over contamination of the hydraulic fluids which
may otherwise lead t o breakdowns and shorten the life of the valves.
line pressure is almost steady and small fluctuation of o il flow due to pressure changes is permitted.
Integrated check valve allows reversed free flow from outlet to inlet port.
Pressure balanced construction provides less effort in adjustment at high pressure.
Recommended Viscosity and Temperatures 2 Viscosity ranging between 15 - 400 mm /s
Please maintain the degree of contamination within NAS 1638-Grade 1 2. Use 25 μm or finer line filter.
ONE WAY RESTRICTORS SRCT/SRCG-03/06/10 (3/8, 3/4, 1-1/4)
which satisfy the recommended viscosity and oil temperatures given above. Control of Contamination
Restrictors One Way Restrictors
This valve is used to regulate an actuator speed in a circuit where
3/8-16 UNC × 1-3/4 Lg. 3/8-16 UNC × 2 Lg. 3/8-16 UNC × 2-1/4 Lg.
Threaded Connections / Sub-plate Mounting
Pressure balanced construction provides less effort in adjustment at high pressure.
Petroleum base oils Synthetic fluids Water containing fluids
Use fluids equivalent to ISO VG 32 or VG 46. Use phosphate ester
or polyol ester fluid. When phosphate ester fluid is used, prefix "F-" t o the model
number because the special seals (fluororubber) are required to be used. Use water-glycol fluid.
Up to 25 MPa (3630 PSI), 500 L/min (132 U.S.GPM)
SRT/SRG-03/06/10 (3/8, 3/4, 1-1/4)
(77 - 1800 SSU). Oil temperatures between -15/+70°C (5 - 158°F). Use hydraulic fluids
