德國賀德克過濾器，HYDAC誠信報價

HYDAC賀德克脫水過濾器OXS    中文描述

HYDAC's OXiStop與集成，液壓驅動的脫氣，脫水機油箱的解決方案。

-水除油

 HYDAC賀德克脫水過濾器OXS    英文描述

HYDAC′s OXiStop is a tank solution with integrated, hydraulically driven degassing and dewatering unit. An integrated membrane prevents direct contact with the ambient air. This means that the tank can be designed for the differential operating volume actually needed, reducing its size. The pump flow rate is not important for the tank design. The fluid attains a very low gas and water content. Thanks to the membrane, which keeps the fluid "vacuum packed", it is also possible to install the OXiStop in extremely dusty or humid environments. HYDAC offers three standard sizes for a differential operating volume up to 70 liters. Additionally, customer-specific solutions can be realized. The OXiStop can be equipped with an optional return line filter, bypass flow filter, water / oil cooler as well as with the AquaSensor AS and the ContaminationSensor CS.

Oil volume reduction typically by a factor of 10

Increased oil service life due to

一個集成的膜防止與外界空氣直接接觸。這意味著，罐可被設計為實際需要的差運算量，降其尺寸。泵的流速是不適合的罐設計很重要。流體達到一個非常的氣體和水分含量。由于該膜，這使流體的“真空包裝” ，但也可以安裝OXiStop在多塵或潮濕的環境。賀德克提供三種標準尺寸的差運算量高達70升。

- 80 % less oxygen content and

- reduced contamination ingression (solid, liquid, gaseous) because of closed system by membrane

Reduced noise due to reduced cavitation by continuous degassing

此外，客戶的解決方案可以實現的。該OXiStop可以配備一個可選的返回線路濾波器，旁路流過濾器，水/油冷卻器以及與AquaSensor AS和ContaminationSensor CS 。

通常油體積減少了10倍

增加了油品的使用壽命因

- 減少80 ％的氧氣含量，

- 減少了污染的侵入，因?yàn)榉忾]系統通過膜（固體，液體，氣體）

減少由于減少氣蝕B噪音

隨著脫水，脫氣和其他流體服務和保健系統， HYDAC提供的解決方案，石油服務的廣泛的產品范圍和護理液壓和潤滑媒體旁路流量。

從HYDAC產品項目既包括移動和固定服務和保健系統。

-通過真空或聚結脫水程序

-消除酸和石油產品老化

-脫氣，維修和保養變壓器油

德國賀德克過濾器，HYDAC誠信報價
