供應p+f電源模塊材質NCN30+U1+NO

Fusing T3A 15/250 V HBC (not accessible)

Rated operating voltage 85 … 132 VAC

184 … 264 VAC

240 … 300 VDC

Rated operating current 2.7 A at 115 VAC

1.3 A at 230 VAC

Supply frequency 47 ... 63 Hz (alternatively, DC possible)

Efficiency typ. 90 % (230 VAC, 4 A)

Galvanic isolation SELV/PELV

AS-Interface power supply, data decoupling, 4 A

General specifications

UL File Number E223176

Current limit starts at > 4.2 A

Current 4 A

Voltage 30.5 VDC ±3 % fixed

Residual ripple < 50 mVSS (500 kHz bandwidth, 50 Ω measurement, with resistive load)

Overvoltage protected limited to max. 55 V

Indicators/operating means

Reset push-button switch earth fault simulation/reset of earth fault display

LED EFD earth fault display; LED red

LED AS-i ok LED green:

ON: AS-Interface voltage OK

OFF: overload or no supply voltage

Electrical specifications

供應p+f電源模塊材質NCN30+U1+NO
