xn好P+F直通式傳感器,倍加福直通式傳感器

xn好P+F直通式傳感器,倍加福直通式傳感器

  • 所屬分類:P+F(倍加福)傳感器
  • 瀏覽次數:
  • 發布日期:2017-03-03
  • 產品概述
  • 性能特點
  • 技術參數

xn好P+F直通式傳感器,倍加福直通式傳感器

電 話:021-39529830轉8009

手 機;18917074297

企業QQ;2880626083

郵箱;18917074297@163.com

聯系人:鄭娜

Thru-beam sensor, M18 threaded housing design,

DC voltage version

Thru-beam sensor, M18 threaded housing design, plastic housing,

front optical face, 20 m detection range, red light, light/dark on,

DC version, 2 PNP outputs, fixed cable

fixed cable, Efficient Line in a short

ffective detection range 0 ... 20 m

M18 plastic housing for standard applications, Very high detection range,

4 LEDs indicator for 360° visibility, Version with front optical face,

透射光束傳感器,M18螺紋外殼設計,塑料外殼,前光學面,

20米檢測范圍,紅燈,亮/暗開,直流版本,2個PNP輸出,固定電纜

DC voltage version, Construction type(S2): Threading M18, Series: GLV18,

Housing diameter: M18, Housing: PC, Light type: modulated visible red light , 640 nm

Efficient Line in a short M18 plastic housing for standard applications

Very high detection range

flashes when falling short of the stability control ; OFF when light beam is interrupted

4 LEDs indicator for 360° visibility

Version with front optical face

MTTFd 630 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 0 %

Indicators/operating means

Function indicator Receiver: LED yellow, lights up when light beam is free,

Threshold detection range 25 m

Light source LED

Light type modulated visible red light , 640 nm

Diameter of the light spot approx. 1300 mm at 25 m

Angle of divergence approx. 3 °

高效線路用于標準應用的短M18塑料外殼

非常高的檢測范圍

4個LED指示燈,用于360°可見度

帶前光學面的版本

直流電壓版本

Functional safety related parameters

plastic housing, front optical face, 20 m detection range,

red light, light/dark on, DC version, 2 PNP outputs,

xn好P+F直通式傳感器,倍加福直通式傳感器
