供應不二越電磁換向閥 ,SAW-G01
上海乾拓貿易有限公司
電 話:021-39529830轉8012
手 機;18917074297
企業QQ;2880626083
郵箱;18917074297@163.com
聯系人:周彩云
地址:上海市嘉定區江橋嘉涌路6號樓713
是監控閥的切換位置,可輸出開關信號的一種電磁切換閥。
由于是通過閥工作直接使開關運作的結構,
Maximum load current 100mA
Residual voltage max 1.2V
So that an accurate switching signal can be obtained.
When the spool is in a neutral state,
較大流量 標準型 30~100 L/min (注1)
Maximum flow standard type 30 ~ 100 L / min (Note 1)
Damping type 30, 50 L / min (Note 1)
The fixed contact is in contact with the movable contact to form an electrically conductive state.
類型 閥芯類型
較大使用壓力 標準型 35MPa
Is the monitoring valve to switch the location, can output a switch signal electromagnetic switching valve.
Because the structure of the switch is operated directly through the valve,
殘留電壓 max 1.2V
Since the magnetic sensor and the proximity sensor are not used,
So the start time of the switching signal is almost independent of the temperature and the direction of operation of the valve.
Series SAW-G01
Type of spool type
Maximum use of pressure standard type 35MPa
Damping type 25MPa
閥芯運轉后,可動接點連動向左側移動,
After the spool is running, the movable contact moves to the left,
Fixed contact and movable contact become non-conductive.
減震型 25MPa
監控開關 定額電壓 DC24V
較大負荷電流 100mA
閥芯處于中立狀態時,
固定接點與可動接點接觸,形成電導通狀態。
減震型 30, 50 L/min (注1)
所以能夠獲得準確的開關信號。
由于不使用磁性傳感器和接近傳感器,
所以開關信號的啟動時間幾乎不受溫度和閥的運轉方向的影響。
系列 SAW-G01
Monitor switch rated voltage DC24V
固定接點與可動接點變為非電導通狀態。
