SMC通用速度控制閥，AS1201F-M5-06A

概述：

Maximum operating pressure 1 MPa max. Applicable tubing

(Release button: White color) ?2, ?3.2, ?4, ?6, ?8, ?10, ?12

? Inch size (Release button: Orange color) ?1/8",

Reduces the mounting height and enables compact machinery design.

?2 size added to applicable tubing sizes ? Metric size

?5/32", ?3/16", ?1/4", ?5/16", ?3/8", ?1/2"

 materials Nylon, soft nylon, and polyurethane tubing are applicable.

Effective area is larger than the former model.

Tube swivels 360° Universal type permits 360° piping swivel.

技術參數：

Fluid Proof pressure Max. operating pressure Mini.

Applicable tubing material (2) Option

–5 to 60°C (No freezing) Nylon, Soft nylon,

 Polyurethane (3) With seal (4),

operating pressure Ambient and fluid temperature

Air 1.5 MPa (1.05 MPa (1)) 1 MPa (0.7 MPa (1)) 0.1 MPa

Round lock nut (5), Electroless nickel plated

SMC通用速度控制閥，AS1201F-M5-06A
