OMRON中間繼電器G2R-2-SND DC24(S) BY OMB

與Push-In Plus插座型P2RF-□-PU組合使用，可縮短60%配線工時(本公司實測值數據) 線圈-接點之間的耐電壓為5,000V，

耐浪涌電壓為10,000V 的安全設計。

 通過對AC/DC線圈膠帶顏色的改變，大大提高了AC/DC規格的識別性。

新增了便于檢查回路的帶閉鎖擺桿型(G2R-□-S(S))。

■額定線圈電流:43.6mA

 ■線圈直流電阻:275歐

■動作電壓:<額定線圈電壓的70%

■復位電壓:>額定線圈電壓的15%

■電壓大值:額定線圈電壓的120%

 ■功率消耗:530mW

外形尺寸: 29.0×13.0×22.5mm(L×W×H)

重 量 : 17g

觸點參數:

觸點形式: 2C(DPDT)

觸點負載: 10A 250VAC 10A 30VDC

阻 抗: ≤30mΩ

額定電流: 10A

電氣壽命:≥10萬回

機械壽命:≥1000萬回

線圈參數:

阻值(士10%):1100Ω

線圈功耗:530mW

額定電壓:DC 24V

吸合電壓:DC 16.8 V

釋放電壓:DC 3.6V

工作溫度:-40℃~+70℃

絕緣電阻:≥1000MΩ

線圈與觸點間耐壓:5000VAC/1分鐘

觸點與觸點間耐壓:1000VAC/1分鐘

G2R-1-S AC120(S) BY OMB

G2R-1-S AC230(S) BY OMB

G2R-1-S AC24(S) BY OMB

G2R-1-S AC240(S) BY OMB

G2R-1-S DC100(S) BY OMB

G2R-2-SN AC220(S) BY OMB

G2R-2-SN AC230(S) BY OMB

G2R-2-SN AC24(S) BY OMB

G2R-2-SN AC240(S) BY OMB

G2R-2-SN DC110(S) BY OMB

G2R-2-SN DC12(S) BY OMB

G2R-2-SN DC24(S) BY OMB

G2R-2-SN DC48(S) BY OMB

G2R-2-SN DC6(S) BY OMB

G2R-2-SN-AP3 AC230(S) BY OMB

G2R-2-SN-AP3 DC24(S) BY OMB

G2R-2-SND DC100(S) BY OMB

G2R-2-SND DC12(N) BY OMB

G2R-1-S DC110(S) BY OMB

G2R-1-S DC12(S) BY OMB

G2R-1-S DC24(S) BY OMB

G2R-1-SD DC12(S) BY OMB
