2636047.0242.24V,HERION單電控電磁閥
介質: 壓縮空氣
接口尺寸: G1/4;NAMUR
驅動: 41031
啟動: 電控/氣彈簧
較大工作壓力: 10bar
工作壓力: 1 ... 10bar
工作溫度: -10 ... 60°C
流量: 1200 l/min
flow_direction: Fixed
主體: 陽極化鋁
材料 - 底座密封: 丁腈橡膠
特點
適用于雙作用執行機構
自由交叉式切換
即便電源失效也能依靠機械彈簧復位
適用于室外惡劣的環境中
2636047.0242.24V,HERION單電控電磁閥
Technical features
Medium:Compressed air,filtered,lubricated or non-lubricated
Operation:Indirect solenoid operated T-spool valves
Operating pressure:max.10bar(see specifications)
Port size:G1/4
Flow direction:Fixed
Mounting:Optional,preferably with solenoid on top
Fluid/Ambient temperature:-20...+60°C
Depending on solenoid system
Air supply must be dry enough to avoid ice formation at temperatures below +2°C
Materials:
Housing:aluminium anodised
Pilot flange:plastic(POM)
Seals:NBR
2636047.0242.24V,HERION單電控電磁閥
